Smart Jacket |Technical Sheet
Dainese The Smart Jacket logo

Technical data

The Smart Jacket offers maximum motorcycle protection with a simple vest that is suitable for all kinds of use. Its simplicity can be attributed to a sophisticated and complex electronics system, developed over more than 25 years of use and testing on the road and track. Take a detailed look at the technical data regarding the Smart Jacket Dainese D-air®.

Airbag technology

Airbag technology

Complete back and chest coverage with the airbag, which involves patented Dainese microfilament technology, for the homogeneous and controlled inflation of the entire airbag area.

THE SMART JACKET
ICON PROTECTED AREAS

Protected areas

Chest and back

ICON CERTIFICATION

Certification

DOLOMITICERT PROCEDURAL GUIDELINE:
  • AIRBAG LEVEL 2 CHEST EN 1621-4 DC
  • AIRBAG LEVEL 1 BACK EN 1621-4 CB
  • DPI (2016/425)
ICON INTENDED USE

INTENDED USE

Optimized for road use

ICON BACK PROTECTOR

BACK PROTECTOR

Absent. The back is covered by the Dainese D-air® airbag system, without the use of a rigid back protector.

ICON INTERFACE

INTERFACE

Multi-LED and Vibramotor

ICON WATERPROOF TECHNOLOGY

WATERPROOF TECHNOLOGY

Totally waterproof electronic system

ICON GPS SYSTEM

GPS SYSTEM

Yes

ICON CONNECTION TO THE MOTORBIKE

CONNECTION TO THE MOTORBIKE

No connection to the vehicle. Operation is guaranteed by the wireless control unit of the Dainese D-air® airbag system.

ICON SWITCHING ON

SWITCHING ON

A magnetic button on the chest

ICON TRACK MODE

TRACK MODE

Not envisaged

ICON AIRBAG REPLACEMENT

AIRBAG REPLACEMENT

To be carried out following an activation, at authorized D-air®, centers and at a cost of USD 299,95

ICON MAINTENANCE INTERVALS

MAINTENANCE INTERVALS

A free check every 3 years, at authorized D-air® centers

ICON BATTERY DURATION

BATTERY DURATION

Up to 26 hours of continuous use

ICON TRAVEL MODE

TRAVEL MODE

Yes, Shipping Mode can be activated via the D-air® app

ICON SYSTEM ARMING CONDITIONS

SYSTEM ARMING CONDITIONS

ICON ON

Even when stationary, with the engine switched on, with identification of bike vibrations

ICON 10KM/H

In motion, at speeds greater than 10 km/h

AIRBAG ACTIVATION SITUATIONS

Rear-end Collision

Rear-end Collision

whether the vehicle is stationary or moving.

Head-on collisions

Head-on collisions

with stationary objects.

Highside

Highside

The rider is thrown due to the rear wheel sliding then unexpectedly regaining traction.

Lowside with and without tumbling

Lowside with and without tumbling

Either the front or rear wheel loses traction and the rider rolls or slides.

Software

ICON DEDICATED APP

DEDICATED APP

Desktop app with dedicated PC and Mac versions.
This allows for Smart Jacket registration and Shipping Mode activation when traveling or transporting the D-air® garment when not in use.

ICON USER REGISTRATION

USER REGISTRATION

Yes, this can be carried out via the D-air® app

LOGO SMART JACKET

All the protection of a Dainese D-air® airbag
with all the lightness of a vest.

All the safety of the Dainese airbag system used in MotoGP™ and developed in more than 25 years of research on the road and track is now encapsulated in a convenient vest that fits any road situation. The Smart Jacket monitors what's happening around the rider 1,000 times a second. It always activates the Shield when necessary, and only then, to provide the rider with maximum protection.
Freedom like this didn’t exist before and won’t be done without ever again.

The most versatile D-air® airbag
